Heavy Duty Bronze Door Closer
Ensure reliable and secure door closure with the NORTON DOOR CONTROLS Heavy Duty Bronze Door Closer. Engineered for high performance, this standard mount door closer is ideal for both interior and exterior use, handling up to 250 lb doors with ease. With adjustable hold-open mechanisms and a robust hydraulic design, it’s built to withstand the demands of frequent, rigorous use.
Key Features:
-
Grade 1 Heavy Duty: Designed for high-traffic areas with 25,000,000 cycles rated performance.
-
Hydraulic Energy Source: Provides smooth and consistent operation for doors up to 250 lb.
-
Adjustable Hold Open: Features latch and back check adjustments for customizable door control.
-
UL Fire Rated: 3-hour fire rating certified, ensuring safety and compliance.
-
Included Hardware: Comes with necessary components for straightforward installation.
Specifications Table:
|
| Specification |
Details |
| Manufacturer Part Number |
PS7500STH x 690 |
| Brand |
NORTON DOOR CONTROLS |
| Closer Mounting Type |
Standard |
| Closer Series |
7500 |
| Closer Type |
Hold Open |
| Color |
Dark Bronze |
| Compatible with Brand |
NORTON RIXSON |
| Display Qty |
1 |
| Display Sell UOM |
EA |
| Max Door Opening Angle |
110 |
| Door Opening – Minimum |
85 |
| Features |
Tri-Packed |
| Finish |
Bronze |
| Fire Rating |
3 hr |
| Housing Depth |
2-1/8 in |
| Housing Height |
3-7/8 in |
| Energy Source |
Hydraulic |
| Includes |
Latch and Back Check Adjustments |
| Includes Hardware |
Hardware Included |
| Door Width Campatibility |
48 in |
| Location Use |
Interior/Exterior |
| Standards |
UL and cUL Listed |
| UL Fire Rating |
UL10C |
| Spring Type |
Adjustable |
| Height Between Mounting Holes |
2-3/8 in |
| Spring Size – Minimum |
1 |
| Material |
Aluminum |
| Door Weight – Maximum |
250 lb |
| Exterior Door Width – Maximum |
38 in |
| Product Type |
Door Closer |
| Projection |
2-1/8 in |
| Spring Size |
6 |
| Arm Type |
Track |
| Closer Cycles |
25,000,000 |
| Hand Orientation |
Non-Handed |
| Housing Length |
13-5/8 in |
| Operation Style |
Manual |
| Performance Duty Rating |
1 |
| Length Between Mounting Holes |
6-3/4 in |
| Ligature Resistance |
Not Ligature-Resistant |
| ADA Compliant |
Yes |
| Performance Rating |
Grade 1 – Heavy Duty |
| Finish C |
Dark Bronze Painted ; Aluminum ; Dark Bronze |
Frequently Asked Questions (FAQ):
Q: How is this door closer mounted?
A: This product features a standard arm mount, attaching to the top of the pull side of the door and frame.
Q: Is this door closer suitable for exterior doors?
A: Yes, it is designed for both interior and exterior use, accommodating doors up to 48 inches wide.
Q: What materials are used for construction?
A: The housing is made of aluminum with a dark bronze finish, ensuring durability and a sophisticated look.
Q: Does it meet ADA compliance standards?
A: Yes, this door closer is ADA compliant, ensuring accessibility in commercial spaces.
Q: Is manual operation easy with this door closer?
A: Yes, the manual operation style with a hydraulic energy source offers smooth and controlled closure.
Elegance Meets Functionality in Every Swing
Imagine the seamless grace with which the NORTON DOOR CONTROLS Bronze Door Closer integrates into your space, combining supreme functionality with understated elegance. Its dark bronze finish not only complements modern and classic designs but adds an aura of robust sophistication. Enhance your entryway by pairing it with a matching bronze-handled door set for a cohesive appearance that resonates luxury. This tool is not merely a closer but a pivotal accessory that enhances both security and aesthetic appeal, essential for the exquisite home or office.
Upgrade your entryways with the perfect blend of durability and style by purchasing the NORTON DOOR CONTROLS Bronze Door Closer today!
