Heavy Duty Adjustable Aluminum Door Closer
The ABILITY ONE Heavy Duty Door Closer provides reliable, adjustable mounting for versatile door configurations, making it ideal for professional installations. Constructed with a robust aluminum finish, this Grade 1 closer supports doors up to 60 inches wide, ensuring smooth and controlled door operation in high-traffic settings.
Key Features:
-
Versatile Mounting: Configure as standard, top frame, or parallel positioning for optimal door fit.
-
Durable Construction: Made of high-strength aluminum for longevity and reliability in heavy-use areas.
-
Smooth Operation: Hydraulic mechanism ensures consistent performance with adjustable spring tension.
-
Compliance & Safety: UL and cUL Listed, ADA Compliant, and ligature-resistant for secure installations.
-
Complete Package: Includes hardware for steel and wood doors; compatible with brands like LCN, Norton, and more.
Specifications Table:
|
| Specification |
Details |
| Manufacturer Part Number |
5340-00-NIB-0296 |
| Brand |
ABILITY ONE |
| Closer Mounting Type |
Parallel |
| Closer Series |
Skilcraft |
| Closer Stop Type |
Spring |
| Closer Type |
Non-Hold Open |
| Color |
Gray |
| Compatible with Brand |
LCN |
| Compatible with Grainger Part Number |
4040 |
| Compatible with Series |
PDQ 7101 |
| Display Qty |
1 |
| Display Sell UOM |
EA |
| Max Door Opening Angle |
180 |
| Door Opening – Minimum |
120 |
| Finish |
Aluminum |
| Housing Depth |
2 in |
| Housing Height |
3-1/2 in |
| Energy Source |
Hydraulic |
| Includes |
Steel and Wood Doors |
| Includes Hardware |
Hardware Included |
| Door Width Campatibility |
60 in |
| Location Use |
Interior |
| Standards |
UL and cUL Listed |
| Spring Type |
Adjustable |
| Height Between Mounting Holes |
2-1/4 in |
| Spring Size – Minimum |
1 |
| Material |
Aluminum |
| Exterior Door Width – Maximum |
54 in |
| Projection |
2-1/4 in |
| Spring Size |
6 |
| Arm Type |
Regular |
| Closer Cycles |
2,000,000 |
| Hand Orientation |
Non-Handed |
| Housing Length |
12 in |
| Performance Duty Rating |
1 |
| Sub-brand |
LCN, Norton, Corbin,Sargent, Yale, Dorma,, PDQ |
| Ligature Resistance |
Ligature-Resistant |
| ADA Compliant |
Yes |
| Performance Rating |
Grade 1 – Heavy Duty |
| Finish C |
Aluminum Painted ; Aluminum ; Gray |
Frequently Asked Questions (FAQ):
Q: What types of doors is this closer compatible with?
A: This door closer works with both steel and wood doors and is compatible with various brands including LCN, Norton, and PDQ.
Q: Can this door closer be used in exterior applications?
A: This closer is primarily intended for interior use, as specified in the product details.
Q: Is the installation hardware included?
A: Yes, all necessary installation hardware is included for a seamless setup.
Q: Does this closer meet ADA compliance?
A: Yes, this closer is ADA compliant, making it suitable for doors requiring accessible operation.
Q: What is the maximum door width this closer can handle?
A: The ABILITY ONE door closer can accommodate doors up to 60 inches in width.
Transformative Functionality with Seamless Design
This ABILITY ONE Heavy Duty Door Closer transcends ordinary functionality with its sleek aluminum design, seamlessly blending into any interior space while ensuring robust door performance. Its modern aesthetic and subtle metallic finish add a sophisticated touch to commercial or residential doorways. Perfect for hallways or entryways, pair this closer with our contemporary handle sets for a flawless finish that embodies both practicality and luxury.
Enhance your space with the sleek functionality of the ABILITY ONE Heavy Duty Door Closerorder yours today!
